Bluetech 2500
Flat solar collector for forced circulation systems, for roof and garden installations

Bluetech 2500
Flat solar collector for forced circulation systems, for roof and garden installations
• Copper plate absorber, ultrasonic welded on 12 copper pipes
dia. 8×0.5 mm, for transferring the thermal carrier fluid, with high selective treatment “h PLUS” (absorption 95% – emission 5%)
• Collector glass 3.2 mm thick, extra clear, tempered and highly transparent
• High density, rear rock-wool insulation, 40 mm thick
• External box in aluminium profiles, with total dimensions 2150 x 1170 x 83 mm
• Collector total surface 2.51 m2, absorbing surface 2.3 m2
• Collector tested and certified according to EN 12975
• 1” connecting unions and gaskets included

Optional:
– Assembly frames and fittings for roof or garden installation for 1, 2, 3, 4, 5, 6 collectors
– Circulation groups
– Solar regulators
– Professional briefcase for thermal solar plants
– Solar circuit filling pump
– AISI 316 L stainless steel piping, dia. 16-20-25 mm
