High Pressure Air Curtains For Commercial And Industrial Doors
• Self-supporting casing construction made of galvanized steel plate, finished in
structural epoxy-polyester painting white colour RAL9016 as standard. Other
colours or stainless steel are available on request.
High Pressure Air Curtains For Commercial And Industrial Doors
• Self-supporting casing construction made of galvanized steel plate, finished in
structural epoxy-polyester painting white colour RAL9016 as standard. Other
colours or stainless steel are available on request.
• Micro-perforated inlet grille with filter functions and easy service. It does not need
prefilter.
• Anodized aluminium outlet vanes, airfoil shaped, adjustable from 0 to 15º each
side.
• EC Double-inlet centrifugal fans driven by an external rotor motor and low noise
level, with very low consumption efficient fans.
• “P” type with water heated coil. “E” type with electrical shielded elements, three
stages with integrated regulation. “A” type without heating, air only. Optional “DX”
with direct expansion coil.
• Includes Advanced Clever control (programmable, automatic, intelligent, energy
saving, Modbus RTU for BMS…) with Plug&Play control and 7m RJ11 cable.
