Recessed Air Curtains For Commercial Doors
• Self-supporting casing construction made of galvanized steel plate, ready to be
installed recessed in a false ceiling.
• Inlet grille (free of maintenance) made with aluminium profiles and blow-out
nozzle, integrated in a single white frame colour RAL 9016. Other colours are
available on request.
Recessed Air Curtains For Commercial Doors
• Self-supporting casing construction made of galvanized steel plate, ready to be
installed recessed in a false ceiling.
• Inlet grille (free of maintenance) made with aluminium profiles and blow-out
nozzle, integrated in a single white frame colour RAL 9016. Other colours are
available on request.
• Anodized aluminium outlet vanes, airfoil shaped.
• Low noise twisted cross-flow fans driven by a 2-speed external rotor motor.
• “P” type with water heated coil. “E” type with electrical shielded elements, two
stages with integrated regulation. “A” type without heating, air only.
• Includes Plug&Play control with 7m RJ45 cable and infrared remote control.
Optional: Clever control (programmable, automatic, intelligent, energy saving,
Modbus RTU for BMS…).
