Compact Recessed High Velocity Air Curtains For Commercial And Industrial Doors
• Compact and low profile air only recessed air curtain, with full grille view, specially
designed for applications without heating.
• Self-supporting casing construction made of galvanized steel plate, ready to be
installed recessed in a false ceiling.
• Inlet grille (free of maintenance) made with aluminium profiles and blow-out
nozzle, integrated in a single white frame colour RAL 9016. Other colours are
available on request.
• Anodized aluminium outlet vanes, airfoil shaped, adjustable in both directions.
• Double-inlet centrifugal fans driven by an external rotor motor and low noise level.
5-speed selector. “EC” models with very low consumption efficient fans.
• “A” type without heating, air only.
• Includes Plug&Play control with 7m RJ45 cable and infrared remote control. Optio-
nal: Clever control (programmable, automatic, intelligent, energy saving, Modbus
RTU for BMS…).
